Megger AVO®830 and 835

---

• TRMS voltage and current measurement
• Dual digital readout
• Classic Megger analogue arc
• 0.1% basic accuracy
• 10 000 count resolution 4 ½ digits
• Phase sequence measurement for 3 phase circuit and motor testing
• 10 MΩ and 10 kΩ input impedance switching
• Non-contact live circuit detection with Hi/low sensitivity
• Resistance from 0.01 Ω to 50 MΩ, conductance and Diode measurement
• Auto and manual range control
• Minimum, maximum and average measurement capture
• Measurement smoothing for fast changing quantity capture
• Hold and Auto Hold modes
• 800 Hz Low pass filter
• Capacitance and frequency measurement
• Temperature measurement*
• IP54 environmental protection

Megger AVO800 series of digital multimeters are the next generation of AVO meters designed for professional electricians, technicians, service personnel and engineers that require high reliability, build quality and performance in a compact, tough, weatherproof case. The AVO830 and AVO835 are true RMS multimeters with up to 1000 V AC, DC and AC+DC voltage measurement ranges* and current measurements from 0.1 mA to 10 A.
