Fujikura Mass Fusion Splicer 41R Kit


Mass Fusion Technology The 41R mass fusion splicer has a wide heating area for up to 4 fibers. The wide electrode gap melts the fibers uniformly and has real-time discharge power control by analyzing the fiber’s brightness intensity. The 41R does not have active core alignment mechanisms, however, during the discharge, the effects of fiber surface tension minimize preexisting offsets. Universal Fiber Holder - The FH-70-4 fiber holder is compatible with many types of fiber ribbon, such as 0.3mm or 0.4mm thick encapsulated ribbons and 200μm or 250μm coated Spider Web Ribbon (SWR). The 250 µm pitch V-grooves in the FH-70-4 fiber holder simplify SWR loading and ribbon preparation. Universal Ribbon Stripper - The RS series ribbon strippers are compatible with 200 µm to 400µm coated fibers without replacing the stripper blades. Universal Tube Heater - The 41R mass fusion splicer can accommodate a max 6.0mm diameter heat sleeve before shrinking. As a result, it supports a wide range of protection sleeve sizes. Simple sleeve centering - The 41R mass fusion splicer features simple sleeve positioning with its designated centering area on top of the tube heater. Easy Maintenance - The CT50 fiber cleaver has a user replaceable blade and rubber clamps – there’s no need to send the device to a service center for blade or clamp replacement.
The 41R is designed for high mobility and includes a wireless communication function, “Active Blade Management Technology”, where the splicer is connected to and monitors the fiber cleaver and ribbon fiber stripper. This functionality greatly prevents operators from making a bad splice due to a worn-out blade position. In addition, both the heating temperature and heating time of the ribbon fiber stripper are automatically changed according to the splice mode setting.
